WHEEL BALANCER GEODYNA 7600

SPECIFICATION

Vehicles supported : Passanger car/Light truck/SUV/Off-road/ Motorcycles ( Optional adaptor required )
Measuring Speed : < 200 RPM
Balancing accuracy : 1 g
Angular resolution : 0.7
Start/stop balancing time : 4.5 s ( wheel 195/64R15 )
Diameter of shaft : 40 mm
Length of shaft : 225 mm
Wheel lift max. load : 70 kg
Power Supply : 230V 1 PH, 50/60 Hz
Dimension L x W x H ( wheel guard open ) : 1381 x 887 x 1834
Net weight : 130 kg

Semi-automatic data entry ( SAPE )
Rim diameter : 8 – 25 inch
Rim width : 9 – 15 inch

Manual data entry
Rim diameter : 8 – 32 inch
Offset : 1 – 20 inch
Rim width : 1 – 20 inch

Maximum wheel dimensions
Max. wheel diameter : 1050 mm
Wheel width range : 76 – 508 mm
Max. wheel weight : 70 kg
